Nacho Grande Supreme 100 LED Off-Road Light
Nacho Grande Supreme 100 LED Off-Road Light
The Grande Supreme 100 is the top-output light in the Grande line: a 6.75-in round LED that puts out 10,696 effective lumens (12,201 raw) and 365,713 peak candela from a 140-watt engine. The optic is a combo, so one fixture covers spot reach, flood spread, and a wide area mode. Tip 2 Chip programming lets you load 3 of 8 modes onto the light, so the same fixture switches from a high-speed driving spot to a low-intensity work light without rewiring.
What separates the Supreme from the rest of the Grande line is the copper circuit board paired with thermal-management software, which lets it hold that 140 W output instead of dimming under heat. It pulls roughly 10 A at 14V, so plan the circuit accordingly. Constant Power builds the relay into the light, so a low-amp switch drives it and you run less harness than a 140 W light usually needs.
It is IP68 sealed against dust and water submersion and J575 vibration rated for trail abuse. The polycarbonate exoskeleton channels air front-to-back for cooling and is field-replaceable and paintable. In the box: the light, two covers (amber NACHO and black ARB), a stainless surface-mount bracket, and hardware. The 2-N-1 mount surface-mounts to a tab or direct-mounts to any 1.5-in tube.
No se pudo cargar la disponibilidad de retiro
Overview
The Nacho Grande Supreme 100 is the highest-output fixture in the Grande line: a 6.75-in round combo LED rated at 10,696 effective lumens from a 140-watt copper-board engine. It is built for high-speed off-road visibility but programs down to a camp-friendly area light.
Key features
- 140 W output: 10,696 effective lumens, 12,201 raw, 365,713 peak candela
- Combo optic: spot, flood, and area light in one fixture
- Tip 2 Chip programming: load 3 of 8 modes with the Sorcery Wand magnet
- Copper circuit board + thermal-management software holds full output under heat
- IP68 sealed, J575 vibration rated, replaceable polycarbonate exoskeleton
- 2-N-1 mount: surface mount to a tab or direct mount to a 1.5-in tube
Use cases
Built for high-speed desert and race visibility where you need long spot reach and wide flood at the same time. The programmable area mode makes it just as useful as overland aux lighting on a roof rack or bumper, then a work light back at camp.
- Diameter: 6.75 in
- Output: 140 W
- Effective lumens: 10,696
- Raw lumens: 12,201
- Peak candela: 365,713
- Amp draw: ~10 A at 14V
- System voltage: 12V DC
- Beam: Combo (spot / flood / area)
- Modes: 8 available, program 3
- Sealing: IP68 (dust + water submersion)
- Vibration: J575 rated
- Housing: Replaceable polycarbonate exoskeleton, forced-air cooled
- Mount: 2-N-1 surface tab or 1.5-in tube direct mount
- In the box: Light, 2 covers (amber NACHO + black ARB), stainless surface-mount bracket, hardware
- Warranty: Lifetime against manufacturing defects
How bright is the Grande Supreme 100, and what beam does it throw?
It puts out 10,696 effective lumens (12,201 raw) and 365,713 peak candela from a 140 W engine. The optic is a combo, so it throws a long spot, a wide flood, and an area pattern all from one fixture.
How do I change the beam modes?
Use the Tip 2 Chip method: tap the chip icon on the light with the included Sorcery Wand magnet to cycle modes. There are 8 modes total and you program your 3 favorites onto the light.
Is the wiring complicated for a 140 W light?
Less than you would expect. Constant Power builds the relay into the light, so a low-amp switch can drive it without a heavy harness. It pulls about 10 A at 14V, so size the supply circuit for that draw.
What size is it and how does it mount?
It is a 6.75-in round light. The 2-N-1 mount surface-mounts to any tab, or you remove the bracket and direct-mount to any 1.5-in tube.
Will it hold up to weather and trail vibration?
Yes. It is IP68 sealed against dust and water submersion and J575 vibration rated. The polycarbonate exoskeleton is replaceable, so if you beat it up off-road you can swap the housing instead of the whole light.
Which covers come with it?
It ships with two covers: an amber NACHO cover and a solid black ARB cover. Smoke, clear, black, and amber covers are sold separately if you want to swap the look.
