Rollercam L Track Surface Mount (2-Pack)
Rollercam L Track Surface Mount (2-Pack)
The Rollercam L Track Surface Mount is a 2-pack of 48 in (4 ft) tracks cut from 6061-T6 aluminum. Each rail has pre-drilled mounting holes every 4 inches, so one track gives you about a dozen anchor points along its length. Bolt the tracks down and you turn a bare truck bed, trailer floor, or wall into a row of slots that Rollercam L-track fittings clip straight into.
This is the anchor base, not a finished tie-down. The pack is two aluminum tracks with smooth, rounded edges. Mounting bolts and Rollercam strap fittings are sold separately, so you build the system that fits your rig. The slot accepts standard 1 in Rollercam L-track ends — both the cam and the straight-end fittings — which means you can re-tension a strap after the load shifts, then pop it loose one-handed when it's time to unload.
Rollercam doesn't publish a single working load limit for the track, and that's on purpose: the real limit depends on the bolts you choose and the surface you mount to. Spec is 1/4-20 or 5/16-18 stainless, 90-degree countersunk flat-head, 1-1/2 in long, with a washer and nut behind each hole. Match the hardware and backing to the load you plan to haul and the track will carry it. The same SKU is also offered in an 8 ft length if you want longer runs.
No se pudo cargar la disponibilidad de retiro
Overview
A 2-pack of 48 in (4 ft) 6061-T6 aluminum L-track that bolts to a flat surface and turns it into clip-in anchor points for Rollercam tie-down fittings. Mounting hardware and strap fittings are sold separately.
Key features
- Two 48 in (4 ft) tracks per pack, 6061-T6 aluminum
- Pre-drilled mounting holes every 4 in (about 12 anchor points per track)
- Smooth, rounded edges to keep gear and hands off sharp metal
- Accepts standard 1 in Rollercam L-track fittings (cam and straight end)
- Surface mount: sits on top of the surface and bolts down, no cutout needed
- Also available in an 8 ft length
Use cases
Built to add fixed tie-down points wherever you need them: truck beds, trailer floors, utility-vehicle decks, even a shop or garage wall. Bolt the tracks where the gear lives, then clip Rollercam cam straps in to lock down coolers, fuel cans, and recovery gear, and re-tension as the load settles on the trail.
- Quantity: 2 tracks per pack
- Track length: 48 in (4 ft) each
- Material: 6061-T6 aluminum
- Mounting holes: pre-drilled every 4 in
- Edges: smooth, rounded
- Mount type: surface mount (bolts on top, no cutout)
- Fitting compatibility: standard 1 in Rollercam L-track ends (cam and straight)
- Recommended fasteners (sold separately): 1/4-20 or 5/16-18 stainless, 90-degree countersunk flat-head, 1-1/2 in long, with washer and nut
- Working load limit: not published (depends on fasteners and mount surface)
- Shipping weight (4 ft pack): 1134 g (about 2.5 lb)
- Other size: 8 ft length available (2268 g)
Are the mounting bolts included?
No. Bolts are sold separately. Rollercam specs 1/4-20 or 5/16-18 stainless, 90-degree countersunk flat-head, 1-1/2 in long, each with a washer and nut on the back of the surface.
What is the working load limit of the track?
Rollercam doesn't publish one number, because the real limit depends on the fasteners you use and the surface you bolt to. The track itself is 6061-T6 aluminum. Pick hardware and a backing surface rated for the load you plan to carry.
Will Rollercam straps and fittings clip into this track?
Yes. Standard 1 in Rollercam L-track ends drop into the slot, both the cam fitting and the straight end. That cam fitting is what lets you re-tension after loading and release with one hand.
What is the difference between surface mount and recessed L-track?
This is surface mount: it sits on top of the bed, floor, or wall and bolts down, no cutout required. Recessed (flush) track drops into a cut opening so it sits level with the surface. Surface mount installs faster and needs no cutting.
How do I install it in a truck bed?
Set the track where you want it, mark the pre-drilled holes, drill through, then bolt it down with a washer and nut behind each hole. You need access to the back of the mounting surface to fit the nuts. Holes are every 4 in, so you get plenty of anchor points along the 48 in rail.
How do I keep the track working over time?
The 6061-T6 aluminum and stainless hardware hold up outdoors. Rinse grit out of the slot now and then so fittings keep seating and sliding cleanly.
